DARRELL

Handmade Aluminum Road Frame

  1. Home
  2. THE BIKES
  3. DARRELL

Ah, aluminum. It’s light, it’s stiff, it’s fast. And yet, not overly harsh. We feel aluminum is a fantastic material. Lighter and stiffer than steel, it lends itself to performance. This is our Darrell.

Aluminum is not an easy material to work with, but in the hands of the right builder it can be both compliant and still transfer power. It can sail over cobbles, or take the bunch sprint, or power up climbs both long and steep. In short, aluminum is rad. Our frame - tapered head tube with an ENVE fork. Triple butted 7005 aluminum main tubes, S-bend seat and chain stays. And gorgeous paint. We believe this is one of the best custom made race bikes available.

The Stoemper Darrell
The Stoemper Darrell
The Stoemper Darrell
The Stoemper Darrell

DARRELL ROAD BIKE GEOMETRY

Size (cm) Effective Top Tube Length Seat Tube (C-C) Head Tube Length Head Tube Angle Seat Tube Angle Chain Stay Length Bottom Bracket Drop
45 490 430 116 72 75 408 70
47 505 450 116 72 74.5 408 70
50 520 480 125 72 74 408 70
52 525 500 125 72.5 74 408 70
54 540 520 138 73 73.5 408 70
55 550 530 145 73 73.5 408 70
56 560 540 160 73.5 73 408 70
57 565 550 160 73.5 73 408 70
58 575 560 180 73.5 73 408 70
60 585 580 200 73.5 72.5 408 70
62 600 600 215 73.5 72.5 408 70

STANDARD FEATURES

  • All Stoemper ALU frames come with a tapered ENVE carbon fork, painted to match.
  • Choose braze-on or 31.8mm clamp type Front Derailleur.
  • Seat posts are always 27.2 mm
  • Default BB is PF30, please let us know if you need a standard BB
  • Tire clearance up to 27 mm no problem
